Hengchuangli double spiral knife crosscutting machine corrugated board production line

Categories	Corrugating Machine Slitter Scorer
Brand	Jumbo Corrugated Machinery Solution
Model	NC-200
color	day
Working width	1800mm
Max mechanical speed	200m/min
Min slitting length	500 mm
Max slitting length	9999mm
Slitting Precision	±1mm (uniform velocity), ±2mm (non-uniform velocit
FOB port	tianjin
Download DOC
Update Time	2022-01-29

Contact Now

Detail Information

Double spiral knife cross cutting machine Product Introduction

(double)

Nc-200 computer spiral knife crosscutting machine Long service life

Remote control
High-accuracy
High safety level
Flexible manufacturing
Competitive price

Product Overview

★ Can store 200 groups of orders, change the size of cutting paper quickly and accurately, do not stop to change the order, and can realize the computer network, convenient production management. ★ Knife shaft transmission gear is made of precision forged steel material, high-frequency quenching, to realize no backlash transmission, the use of advanced key-less connection, high transmission accuracy. ★ The blade of crosscutting machine adopts the structure of inlaid steel spiral knife and serrated knife. ★Scissor type shearing, small shearing force, long blade life. ★ Both front and rear feeding wheels adopt sun wheel paper pressing mode, stable conveying, uniform pressure, not easy to crush the board or cause blockage. ★ This machine is energy storage brake (non-energy consumption brake), so in the production process of low energy consumption, the average electricity consumption is the ordinary NC cutting machine 1/3, save more than 70% electricity, to achieve the goal of money saving. ★Precision adjustable gear without backlash, to ensure the precise engagement of the tool edge, operation balance. ★ Independent oil-immersed gear lubrication is more energy saving, safe and reliable, lubrication and cooling. ★ Knife roller: high quality precision forged steel, balance treatment, with good stability.

What we can do for you?

Our Services

Reply your inquiry in 24 working hours.(our normal working time:6:00~22:00)
Experienced staffs answer all your questions in time.
Customized design is available.
Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.
Special discount and protection of sales are provided to our distributor.
Professional factory: We are manufacturer, specializing in producing all kinds of CNC MACHINING CENTER.
As an honest seller, we always use superior raw material, advanced processing/testing machines, skilled technicians to ensure our products to be finished in hight quality and stable feature.

If the above model is not suitable for your workpiece, please tell us your need and then we can send you the most satisfying drawing.: contact us
